parameters:
|
material spec |
sheet, galvanized steel sheet, aluminum sheet |
|
thickness of material |
1.5-2.7 mm |
|
roller material |
High grade NO. 45 forged steel with 0.05mm hard chrome plating |
|
shaft material |
High grade NO. 45 carbon wrought steel |
|
cutting blade |
Cr12 mould steel with quenched treatment |
|
diameter of shaft |
75 mm |
|
forming steps |
20 rows |
|
productivity |
10-12 m/min |
|
power |
15 KW |
|
controlling system |
PLC control |
|
appearance size |
10000mm*1150mm*1510mm |
|
hydraulic oil |
46# hydraulic oil |
|
Electric tension |
380V 50 Hz 3 Phase or as your requirements |
Packing Method
Main machine is packaged with plastic film
Transportation
All machines need one 20 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time
Within 30 days after receiving deposit.
Warranty
Two years, and we will provide technical support for wholelife of the equipment.
If some parts of machine broken within 2 year, we will give customer the spare parts for free. （include chain, bearing, roller,oil pipe, counting wheel） If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
Price: 47000-50000$/set
Min Order: 1set
Place of Origin: Hebei, China
Certification: CE
