Product introduction:

Profile bending machine at both horizontal and vertical, depending on the axis arrangement can be divided into up-regulated and down-type formula, which is curved aluminum profiles, flat steel, round steel, angle steel, I-beam, H steel, square tube, advanced machine rectangular tube, pipe and other profiles. Different molds can be customized according to user requirements. 4 rolls are active roll, there are four independent hydraulic motor.

Characteristic:

Profile bending machine features: profile bending machine can complete a feeding pre-bending profiles, roll round and round the school processes; advanced profile bending machine structure, full-featured, stand up or lying down can be based on user usage.

 have light weight, high strength, bearing great and good vibration resistance.There are widely used in high construction.It’s have a variety of styles,that’s both substantial price and beautiful.



Parameter:

material spec	colored steel sheet, galvanized steel sheet, aluminum sheet
thickness of coil sheet	0.2-0.7 mm
material expand width	1220 mm
roller material	high grade NO. 45 forged steel with 0.05mm hard chrome plating
shaft material	high grade NO. 45 carbon wrought steel
cutting blade	Cr12 mould steel with quenched treatment
diameter of shaft	70mm or as your requirement
main frame	300 H steel
forming steps	3 rows
productivity	3-4m/min
hydraulic station power	3 KW
hydraulic pressure	10-12MPa
controlling system	famous PLC computer control
material of  cutting table	Cr 12 mould steel with quenched treatment
appearance size	2500mm*1500mm*1510mm
hydraulic oil	46# hydraulic oil
Electric tension	380V 50 Hz 3 Phase or as your requirements



Packing Method

Main machine is packaged with plastic film

Transportation

All machines need one 20 feet container to hold

Payment Term

30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.

Delivery Time

Within 30 days after receiving deposit.

Warranty

Two years, and we will provide technical support for wholelife of the equipment.

If some parts of machine broken within 2 year, we will give customer the spare parts for free. （include chain, bearing, roller,oil pipe, counting wheel） If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.

Price: 5000$/set

Min Order: 1set

Place of Origin: Hebei, China

Certification: CE
